K3000 Polyurethane Spray & Injection Machine

Description：

K3000 is a professional, cost-effective polyurethane spray and injection machine. It is equipped with a specially designed horizontal booster pump, which not only has small fluctuations in working pressure, but also has less wearing parts and is easy to maintain.

Application：

Construction, Automobile, Road, Railway, Shipbuilding, Mining, Petroleum, Electrical, and other industries.

Availability:



Inquire Add to Basket

Product Description

K3000 Polyurethane Spray & Injection Machine is a professional, cost-effective polyurethane spray and injection machine. It is equipped with a specially designed horizontal booster pump, which not only has small fluctuations in working pressure, but also has less wearing parts and is easy to maintain.

Polyurethane Spray & Injection Machine

DETAILED PARTS

Technical Parameters
Model	K3000 Polyurethane Spray Machine
Applicable materials	Polyurethane
The ratio of raw material	1:1
Viscosity range of raw materials	200-1000CPS (under working temperature)
Max working pressure	20MPa
Max fluid temperature	80°C
Max output	l1kg/min
Max heated hose length (Optional)	90m
Heater power	4500Wx2
Heated hose max power	3000W
Drive mode	Full pneumatic
Clean mode	Self-cleaning by air
Voltage (Optional)	Single phase 220V 50Hz or Three phase 380V 50Hz
Whole power	13kw
Pneumatic source	0.6-0.9Mpa lm³/min

APPLICATION INDUSTRY

MAINFRAME

MAINFRAME

TRANSFER PUMP

HEATED HOSE

HEATED HOSE

SPRAY GUN

SPRAY GUN

STANDARD CONFIGURATION

STANDARD CONFIGURATION

Standard Configuration
Reanin-K3000 mainframe	1 set	Heated hose	15m
Reanin spray gun	1 set	Transfer pump hose	2 pcs
Transfer pump	2 sets	Whip hose	2 pcs
Air pipe	1 set	Tools and spare parts	1 set
English user manual	1 set	Protective clothing and mask	1 set
